What you drink makes you different
KYK 66000
Platinized with platinum Titanium electrode plates
ON/OFF and Function Select One-touch Sensor Buttons
Nine Types of Customized Water Types: Four Alkaline Levels, Four Acidic Levels, One Purified Water
Daily Available Filter Lifespan Counting for Control
Built-in Large Volume Purification Filter with Filter Control System
Using Platinized Titanium Electrode
Patents on diaphragm Membrane Structure including Electrode Plate for the Electrolytic Cell of Water Ionizer
SMPS Power Control System
Automatic Cleansing and Water Drainage System of Stagnant Water from Filter and Electrolysis for more Sanitary
Auto Cleansing and Water Drainage System after Usage
Water is Essential for our Body! Which Type of Water are You Drinking?
KYK Alkaline Water Helps improving symptoms of Common Gastrointestinal Problems
Specification
This product is connected directly to tap water and creates alkaline reduced water by first purifying the water with two special hybrid filters, then ionizing the water using 5 or 7 platinized titanium plates
| Manufacturer Approval Code | No. 2213 |
|---|---|
| Medical Device Approval Code | No. Huh-08-730 |
| Product | Alkaline water ionizer |
| Model | KYK 66000 |
| Manufacturing Company | KYK Co. Ltd. (440-407 Sangdaewon-Dong Joongwon-Gu, Sungnam City, Kyunggi-Do, Korea) |
| Manufacturing Number/Date | See the Backside of the Product |
| The object of Product | Alkaline Water Ionizer which can produce pH8.5 up to 10.0 alkaline ionic water by drinking water electrolysis to improve symptoms of chronic stomach problems-chronic diarrhea, indigestion, intestinal dysbiosis and hyperacidity |
| Standard Voltage and Frequency | 220V AC / 60Hz |
| Electrical Consumption | 130VA |
| Size / Weight | Size : 365(H)mm X 280(W)mm X 156(D)mm / Weight : 6kg |
| Composition / Water Supply Type | Stationary or wall-mounted / Direct connection to tap water |
| Controlling Method | Touch sensor |
| Available Temperature | 5ºC ~ 40 ºC |
| Available Water Pressure | 3.0kgf/cm2 |
| Electrolysis Method | Continuous electrolysis (Built-in water flow sensor) |
| LCD Display | Display pH level |
| Output Capacity | 2.5 liters per minute(0.5L/min) |
|---|---|
| Electrolysis Ability | 4 levels of acidic water, 4 levels of acidic water, filtered only water |
| Electrolysis Cell | Platinized with platinum Titanium electrode plates and the diaphragm |
| Electrode Sheet Wash | Automatic washing(Auto-wash after usage by mycom control system) |
| Filter Lifespan | 3,500ℓ in 6 months approximately(Depending on the raw water quality of region or nation, the Filter life may be shorten.) |
| Indicate Filter Change | ①After 6 months later from the last filter replacement date. You should replace the filter promptly, even though the filter life does not come to the end. ② You should replace the filter promptly, If the water’s taste, smell, color etc. is not normal condition because of the decline in regional raw water quality or a period of water shortage, even though the filter life does not come to the end. |
| Filter kind | Complex filter |
| Filter change instructions | Filter Change (see the user manual) |
| Power Source Protector | Fuse |
| Over-current Detector | Automatically stops the output of electrolytic cells |
| Over Temperature Protector | Temperature detector circuit installed inside SMPS power supply automatically stops the device |
