What you drink makes you different
Filter Sensor and Filter Control System
pH Level and Water Liter Per Minute Displayed on LCD Screen
Each pH Level Displayed into Seven Different Colors
Filter Sensor and Filter Control System
SMPS Power Control System
Patents on diaphragm Membrane Structure including Electrode Plate for the Electrolytic Cell of Water Ionizer
pH Auto-Control System
Auto Cleansing and Water Drainage System after Usage
Five Types of Water: Four Alkaline Level, One Purified Water
KYK Alkaline Water Helps improving symptoms of Common Gastrointestinal Problems
This product is connected directly to tap water and creates alkaline reduced water by first purifying the water with two special hybrid filters, then ionizing the water using 5 or 7 platinized titanium plates
| Manufacturer Approval Code | No. 2213 |
|---|---|
| Medical Device Approval Code | No. In-07-667 |
| Product | Alkaline water ionizer |
| Model | Generation ll |
| Manufacturing Company | KYK Co. Ltd. (440-407 Sangdaewon-Dong Joongwon-Gu, Sungnam City, Kyunggi-Do, Korea) |
| Manufacturing Number/Date | See the Backside of the Product |
| The object of Product | Alkaline Water Ionizer which can produce pH8.5 up to 10.0 alkaline ionic water by drinking water electrolysis to improve symptoms of chronic stomach problems-chronic diarrhea, indigestion, intestinal dysbiosis and hyperacidity |
| Standard Voltage and Frequency | 220V AC / 60Hz |
| Electrical Consumption | 180VA |
| Size / Weight | Size : 340(W)mm X 340(H)mm X 150(D)mm / Weight : 6kg |
| Composition / Water Supply Type | Stationary or wall-mounted / Direct connection to tap water |
| Controlling Method | Touch sensor |
| Available Temperature | 5ºC ~ 35 ºC |
| Available Water Pressure | 3.0kgf/cm2 |
| Electrolysis Method | Continuous electrolysis (Built-in water flow sensor) |
| Display(4-Digit FND method) | Display pH level and ORP level, 7 different colors of each level, water flow rate per minute, operation, filter usage(1st, 2nd, and 3rd), auto-diagnosis for error, water purification, and voice alert etc. |
| Output Capacity | 2 liters per minute(0.5L/min) |
|---|---|
| Electrolysis Ability | 4 levels of acidic water, 4 levels of acidic water, filtered only water |
| Electrolysis Cell | Platinized with platinum Titanium electrode plates and the diaphragm |
| Electrode Sheet Wash | Automatic washing(Auto-wash after usage by mycom control system) |
| Filter Lifespan | 1st :6 months/6000ℓ, 2nd: 12 months/ 9000ℓ |
| Indicate Filter Change | ①After 6 months later from the last filter replacement date. You should replace the filter promptly, even though the filter life does not come to the end. ② When the available usage amount has been reached to 70ℓ ③ You should replace the filter promptly, If the water’s taste, smell, color etc. is not normal condition because of the decline in regional raw water quality or a period of water shortage, even though the filter life does not come to the end. |
| Filter kind | 1st filter :Complex filter, 2nd filter: Complex filter |
| Filter change instructions | Filter Change (see the user manual) |
| Power Source Protector | Fuse |
| Over-current Detector | Automatically stops the output of electrolytic cells |
| Over Temperature Protector | Temperature detector circuit installed inside SMPS power supply automatically stops the device |
